Product Overview
This machine is suitable for industries such as rubber and plastic, paper products, color printing packaging, adhesive tapes, luggage and handbags, daily chemicals, and electronics. It can test the physical properties of various materials, finished products, and semi-finished products. By purchasing various different fixtures, it can perform tensile, compressive, tensile holding, compressive holding, bending, tearing, peeling, adhesion, and shear tests. The structure features high-precision, low-resistance Taiwan TBI ball screws and guide columns enclosed within an aluminum extrusion frame treated with high-grade baking varnish. The measurement and control system has a high data acquisition and calculation speed, and the test results can be displayed on the touch screen or printed by a printer. The product is stable and reliable in performance, highly accurate in measurement, and easy to operate.
Instrument parameters
| Item | Parameter Range |
|---|---|
| Capacity Options | 5, 10, 20, 50, 100 kg |
| Display | LCD display |
| Measuring Accuracy | ±1% |
| Resolution | 1/200000 |
| Test Speed | 0～300 mm/min |
| Effective Stroke | 600 mm |
| Test Space | 1200 mm |
| Force Units | kgf, gf, N, kN, lbf |
| Stress Units | MPa, kPa, kgf/cm², lbf/in² |
| Stop Mode | Upper/lower limit safety setting, specimen break detection |
| Result Output | Micro printer |
| Overall Dimensions | 480×390×1350 mm (LWH) |
| Machine Weight | Approx. 40 kg |
| Power Supply | 1PH, AC 220V, 50/60Hz |
| Power | Speed regulating motor |
| Optional | Tensile fixture (standard) |
